LWR300 Lidar Wind Radar

- 30m~1000m wind speed and direction measurement
- 1550nm eye-safe laser
- Solid-state optical scanning technology
- Integrated electronic compass, support automatic north finding
- Built-in GNSS+4G module for remote communication and positioning





Lidar Wind Radar





LWR300 lidar is a high-precision, high-resolution, large detection range wind radar, and can provide three-dimensional wind field information under clear sky conditions. It has the advantages of fast response, small size, compact structure and strong environmental adaptability, and can be widely used in meteorological detection, environmental monitoring, wind energy assessment, airport early warning, emergency support and other fields.

LWR300 lidar wind radar can replace wind towers for three-dimensional wind speed and direction observation, and can also be used as an effective supplement to traditional wind profile radar for low-altitude measurement. It can provide vertical gradient data for atmospheric composition monitoring in urban haze monitoring applications. It is a convenient and reliable vertical detection instrument.

-  30m~1000m wind speed and direction measurement
-  1550nm eye-safe laser
-  Solid-state optical scanning technology
-  Integrated electronic compass, support automatic north finding
-  Built-in GNSS+4G module for remote communication and positioning










Vertical wind speed and direction measuring
Height range     30m~1000m
WS measuring range     0.5m/s~50m/s
WD measuring range     0~360°
WS measuring accuracy     ±0.5m/s
WD measuring accuracy     ±8°
Height resolution

The minimum measurement layer is 20m

(within thepulse/detection height range or can be manually set)

Time resolution     10s
Ambient humidity measuring*
RH measuring range     0%RH~100%RH
RH meansuring accuracy     ±3%RH (10%RH~90%RH)、±5%RH(90%RH~100%RH)
RH resolution     0.1%RH
Ambient temperature measuring*
T measuring range     -30℃~55℃
T meansuring accuracy     ±0.3℃,±0.2℃(5℃~35℃)
T resolution     0.1℃
Ambient air pressure measuring*
Pressure measuring range 300hPa~1100hPa
Pressure meansuring accuracy ±0.3hPa(0~50℃),±0.5hPa(-30~0℃)
Pressure resolution 0.1hpa
Ambient wind speed measuring*
WS measuring range 0-50m/s
WS measuring accuracy ±0.5m/s (0-15m/s), ±4% (>15m/s)
WS resolution 0.1m/s
Ambient wind direction  measuring*
WD measuring range 0-360°
WD measuring accuracy ±2° (<±10°), ±4° (>±10°)
WD resolution 0.1m/s
General parameters
Operating wavelength 1550nm
Continuous working time 7×24h
Power supply 24VDC
Power consumption 30~75W
Interface RS232/485,USB,LAN,Wi-Fi
GPS function GPS, Beidou, GLONASS, Galileo, QZSS
Compass function Three-axis electronic compass, automatic north finding
Operating temperature -20℃~55℃
Storage temperature -50℃~85℃
Humidity range 0~100%RH
Altitude range ≤4000m
Protection performance Rainproof, anti-salt spray, anti-sand, anti-vibration, anti-shock
Shell material Aviation aluminum alloy
Dimensions 439mm×355mm×590mm
Weight Around 40kg





Dimensions:439×355x590mm

Weight:40kg
Working environment:-20℃~50℃,0~100%RH
